Stone Machinery HLWJ-4020P Water Jet Cutting Machine 5 Axis Cnc Water Cutter Waterjet Cutting Machine

• Type
  • CNC machine
• Use
  • Stone processing
• Voltage
  • AC380V/50Hz
• Cutting thickness (max)
  • 120 mm(4.72in)
• Power(w)
  • 46.5 KW(62.36hp)
• Core components
  • Bearing
  • Motor
  • Gear
  • Gearbox
• Key selling points
  • Automatic
• Warranty
  • 1 Year
• Machinery test report
  • Provided
• Video outgoing-inspection
  • Provided
• Production Capacity
  • high
• Place of origin
  • China
  • Fujian
• Weight
  • 5000 kg(11023.11lb)
• Dimension(L*W*H)
  • 5200x2300x2200mm(204.72x90.55x86.61in)
• Control system
  • CNC
• Max.working pressure
  • 4137bar(60000psi) 400MPa
• Sustainable operating pressure
  • 360-380MPa
• Max. flow rate
  • 3.6 L/min
• Main motor power
  • 37 kw
• Max. diameter of orifice
  • 0.33 mm
• Cooling type
  • water cooling
• Driving system
  • AC servo
• Rail guide
  • Linear bearing
• Transmit way
  • Ball screw
• Packaging Details
  • 1) Covered by plastic film wholely. 2) Packed in plywood cartons for spare parts. 3) Locked with steel ropes for anti-skid suitable for shipment by container.
• Selling Units
  • Single item
• Single volume
  • 0 cm3
• Single gross weight
  • 0.0 kg
• Model number
  • HLWJ-4020P
  • HLWJ-2515P
• Working Area
  • 4100*2100mm(161.42*82.68in) + $ 3,250.00
  • 2600x1600mm(102.36x62.99in)
• Certifications & Compliance
  • CE
