Design
We have professional engineers design team,and can use CAD
Pro-E,UG,Solidworks etc.
Before the project started
1, If you have 3D STEP/IGES/X_T drawing or 2D drawing, please directly send to us
before quotation, then we will do DFM and mould design for you.
2, If you have samples no drawings, please directly provide us samples, we can design
3D for you,and quotation.
Mould Information
| Mold information | Content |
| Product Material | ABS,PP,PC,PA,PMMA,PS,POM and etc. |
| Moldbase | FUTABA,LKM,HASCO,DME you can choose |
| Cavity material | 45#,50#,P20,H13, 718 2738, NAK80, S136, SKD61 etc |
| Runner | Cold/Hot runner |
| Cavity | Multi or single cavity |
| Standart parts | Hasco |
| Gate type | Side gate,Sub gate,Pin point gate,Edge gate etc |
| Treatment | Heat treatment and Nitriding,polish ect. |
| HRC | H45~52 |
| Tooling lifespan | 300,000-1,000,000 shots |
| Machine type | 90~650Ton |
| The standard of appearance of the products for stripe | MT(Mold Tech),YS,HN series |
| Lead time | 15~30 days |
| Plastic Mold (Moulds) production process | Description |
| 1. 3d Design/Samples for quotation | According to 3D drawing or samples for quotation. |
| 2.Negotiations | Including the price of moulds, moulds sizes, material for cores & cavities, weight of product, part cost, payment, moulds lifetime, delivery, etc. |
| 3. Purchasing Order | After the customer confirming the mould design and quotation. |
| 4. Making mold(moulds) | Confirm drawing, start to do DFM,mold flows and mold detail agreed with the customer, start production. |
| 5. Production schedule | Every week we will feedback to the customer a mold progress(picture). |
| 6. sample shoot | We provide the moulds test samples for confirmation(about 10-15 piece), then, get your signature sample,mass production. |
| 7. Package | Wooden case for moulds, cartons for parts,or as your requiretment. |
| 8. Delivery | deliver goods by air or by sea. |
| Item Name | I-M |
| Service | C Plastic/Metal Prototypes |
| 2.Vacuum casting/vacuum forming(Silicon Mould) |
| 3.Low Volume Production |
| 4.Rapid Hardware/Sheet Metal Prototypes |
| C Aluminum/Brass/Copper/Bronze CNC machining/machined parts |
| tomotive and medical equipment Prototypes |
| 7.SLA/SLS prototype |
| tal Stamping&NCT Stamping |
| 9.3D Printing |
| 10.Die-casting, hardware machining |
| 11.Electronic Manufacturing Service |
| jection mould&Plastic Injection |
| 13. Lathing parts |
| sign service (OEM service) |
| Certification passed | Bureau Veritas,ROHS,ISO |
Q1:Where can I get product&price information?
A1:Send us inquiry
Q2:How long can i get the sample?
A2:Depends on your specific items,within 3-7 days is required generally.
Q3:What's kinds of information you need for quote?
A3:Kindly please provide the product drawing in PDF,and will be better you can provde in STEP or IGS
Q4: what's the payment terms?
A4: We accept 50% as payment deposit, when the goods is done, we take photoes for your check and you then pay the balance.
For small amount, we accept Paypal, Paypal commission will be added to the order. For big amount, T/T is preferred
Q5: How to delivery the goods?
A5:We deliver the products by courier company
A6:We are direct factory with 17 experienced engineers and more than 50 employees as well approximate 5,000 square meters workshop area.
Q7. What shall we do if we do not have drawings?
A7. Please send your sample to
Q8. Can we get some samples before mass production?
A8:Absolutely
Q9. Will my drawings be safe after sending to you?
A9:Yes, we will keep them well and not release to third party without your permission.
Q10: Is it possible to know how are my products going on without visiting your company?
A10: We will offer a detailed production schedule and send weekly reports with digital pictures and videos which show the machining progress. Q11: If you make poor quality goods,will you refund our fund?
A11: As a matter of fact, we won't take a chance to do poor quality products. Meanwhile, we manufacture goods quality products until your satisfaction.
