Name: Professional Hydraulic Crawler Type Deep Water Well Drilling Rig Mine Drilling Machine
SKU: B2B-38864
Price: 16610.0 USD
Availability: PreOrder

Product description

Introduction

Type	HFX400	HFX700	HFX500	HFX1200	HFX2000
Drilling capability	Max. depth	m	400(∅89)	700(∅89)	500(∅89)	1200(∅89)	2000(∅114)
Max. diameter of working floor	mm	∅330	∅500	∅500	∅500	∅610
Feeding system	Max. lifting capacity	KN	200	360	280	600	1000
Max.feeding capacity	KN	80	150	120	160	260
Max.lifting speed	m/min	30	32	39	31	43
Max.feeding speed	m/min	60	60	57	45	50
Stroke	mm	6600	7000	7000	5000	15200
Top drive	Max.torque	N.M	8300/4150	15000/7500	11000	21000/10500	32000/19000
Max.Speed	r/min	80/160	75/150	143	70/140	105/180
I.D	mm	∅45	∅55	∅55	∅105	∅105
Floating distance	mm	100	60	100
Max.tilting angle	°	85	85
Deck engine	Type	T480	T400	C220	T301	TAD1643VE
Rated power	kw	92	154	164	191	405
Main winch	Hoisting capacity	42	42	50	42
Tool winch	Hoisting capacity	KN	15	15	15	15	15
Breakout device	Max.breakout torque	KN	95000
vise clamping range	N.M	2-7/8" ~ 10-6/8"
Foam pump	Max. flow	mm	18(Optional)	35(Optional)	35(Optional)	35	50
Max. pressure	L/min	4(Optional)	4(Optional)	4(Optional)	4	15
Mud pipe	I.D	Mpa	∅51	∅51	∅55	∅76	∅76
Max. pressure	mm	8	8	8	8	21
Chassis	Drive mode	Mpa	Crawler chassis	Crawler chassis	Car chassis	Crawler chassis	Crawler chassis
Rated power	kw
High speed	km/h	2.9	2.2	2.3	2.4	2.5
Max.climbing gradient	%	39	39	39	39	39
Working dimension(LWH)	mm	4280 x 3130 x 9300	5036 x 3570 x 9970	10200 x 3600x 11250	6450 x 3700x 13020	8800 x 4500 x 22090
Transportation dimension(LWH)	mm	5800 x 1800 x 2400	6280 x 2250 x 2925	12000 x 2500 x 4200	12700 x 2250 x 3090	14400 x 3000 x 3600
Weight	t	9	13.7	23	18	50

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

15 days
Step 3

Packaging and dispatch

Packaging details are available on request.

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 29 fields

Usage

Water Well

Type

water well drilling rig

Drilling Depth

Max.2000m

Drilling Diameter

330-610mm

Power Type

Diesel

Voltage

220V/380V

Core components

Bearing, Gear, Engine

Warranty

1 Year

Machinery test report

Provided

Video outgoing-inspection

Provided

Key selling points

deep water well drilling rigs

Place of origin

China, Henan

Weight

13500 KG

Dimension (L*W*H)

6210 x*2250 *2880mm

Mobility

Crawler Type

Max. lifting capacity (Specification)

160-1000kn

Max.feeding capacity

80-260kn

Max.lifting speed

32-43m/min

Max.feeding speed

60-50m/min

Stroke

7000-15200mm

High speed

2.4-3km/h

Max.Torque

31500/21000

Application

geothermal well

Feature

deep Water Well Drilling Rig

Selling Units

Single item

Single package size

621X225X288 cm

Single gross weight

6800.0 kg

Power (W) (Product option)

92-571kw

Model number

Accessories, HFX Series

Lead time

15 days

Minimum order

1 Units
