Product description

Highlights at a glance

The LPC-M online particle counter is photoresist (light shading) counting principle specified by the International Hydraulic Standards Committee. It is specially used for on-line measurement of oil contamination level. It has the advantages of small volume, light weight, fast detection speed, high precision and good repeatability, and can work under high temperature and high pressure environment. It is applicable for the measurement of engine oil, gear oil, transformer oil (i.e. insulating oil), hydraulic oil, lubricating oil, synthetic oil and other oils, widely used in aerospace, petrochemical, transportation ports, steel metallurgy, automobile manufacturing and other fields.

Technical Parameters

1. Light source: semiconductor laser

2. Flow rate range: 20-500mL/min

3. Viscosity of the sample to be tested: ≤350cSt

detection pressure: 0.1-0.6Mpa (optional decompression device maximum pressure up to 40Mpa)

5. Particle size range: 1-500μm (select different types of sensors)

6. Interface: USB interface, RS232 interface, RS485 interface

7. Data storage: Provide 1000 sets of data storage space and support USB storage

8. Sensitivity: 1μm or 4μm (c)

9. Limit coincidence error: 10,000 grains/ml

10. Counting volume: 1-999ml

11. Counting accuracy:±0.5 pollution degree levels

12. Protection level: IP56

13. Test interval: 1 second - 24 hours

14. Test sample temperature: 0-80℃

15. Working temperature: -20-60℃

16. Power supply: AC 220V±10%, 50/60Hz or DC12-40V

17. Weight: 3kg

18. Volume: 30* 25*25mm

Frequently asked questions

Generally it takes about 10 working days for production and then the delivery will be done timely.

The package is made of international export standard wooden case.

By train, by air, by sea, by truck, by express, etc.

The guarantee period is 1 year due to the product quality problems itself.

Online support through

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

10 days
Step 3

Packaging and dispatch

Air + Express via FLY Logistics · Approx. shipping fee: $ 16.00 for 1 set · Transit time: Est. 8-9 days

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 20 fields

Type

Testing Machine

Application

Lab Testing, Diesel Testing, Oil Testing, Water Testing, oil quality analysis

Accuracy Class

Standard Accuracy

Voltage

220 V, 110 V, 240 V

Protection Class

Ip56

Warranty

1 Year

Customized support

OBM

Power

100

Accuracy

0.1

Place of origin

China, Chongqing

Product start-up time

10 seconds minimum

Measurement period

Default 30 seconds run time, 15 sec

Reporting interval

On board data storage every second. Output via RJ45 connection

Principle of operation

Laser diode optical detection of actual particulates

Working viscosity

1-300 cSt

Ambient storage temperature for unit

40°C to +80°C, 40°F to +176°F

Selling Units

Single item

Single package size

30X25X25 cm

Single gross weight

3.000 kg

Model number

LPC-M

Lead time

10 days

Minimum order

1 Units
