Product description

3000W Cutting Parameters
Mild Steel O2
Thickness (mm)	Cutting Power （W）	Focus (mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	1200	1	O2	6	S1.5	9 · 12
2	1400	2	O2	0.6-1.0	D1.0	5 · 6
3	3000	3	O2	0.6-1.0	D1.0/D1.2	4 · 4.5
4	3000	3	O2	0.6-1.0	D1.0/D1.2	3.2 · 3.8
5	3000	3	O2	0.6-1.0	D1.0/D1.2	3.2 · 3.4
6	3000	3	O2	0.6-1.0	D1.0/D1.2	3 · 3.2
8	3000	3	O2	0.6-1.0	D1.2	2 · 2.3
10	3000	3	O2	0.6-1.0	D1.2	1.5 · 1.7
12	3000	3	O2	0.6-1.0	D2.0/D2.5	0.8 · 1
14	3000	3	O2	0.6-1.0	D2.5/D3.0	0.8 · 0.9
16	3000	3	O2	0.6-1.0	D3.0	0.7 · 0.85
20	3000	4	O2	0.6-1.0	D3.5	0.65 · 0.8
Mild Steel Air
Thickness (mm)	Cutting Power （W）	Focus （mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	3000	1	Air	16	S2.0	25 · 30
2	3000	2	Air	16	S2.0	12 · 15
Stainless Steel N2
Thickness (mm)	Cutting Power （W）	Focus （mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	3000	1	N2	12	S2.0	30 · 40
2	3000	1.5	N2	12	S2.0	15 · 18
3	3000	2.5	N2	13	S2.0	8 · 10
4	3000	3.5	N2	13	S2.5	5.4 · 6
5	3000	4	N2	16	S2.5	2.8 · 3.5
6	3000	4.5	N2	16	S3.0	1.8 · 2.6
8	3000	5.5	N2	16	S3.0	1.0 · 1.3
10	3000	6	N2	16	S3.5	0.6 · 0.8
12	3000	7	N2	20	S4.0	0.5 · 0.7
Stainless Steel Air
Thickness (mm)	Cutting Power （W）	Focus （mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	3000	1	Air	16	S2.0	30 · 40
2	3000	1.5	Air	16	S2.0	15 · 18
3	3000	2.5	Air	16	S2.0	8 · 10
4	3000	3.5	Air	16	S2.5	5.4 · 6
5	3000	4	Air	16	S2.5	2.8 · 3.5
6	3000	4.5	Air	16	S3.0	1.8 · 2.6
8	3000	5.5	Air	16	S3.0	1.0 · 1.3
10	3000	6	Air	16	S3.5	0.6 · 0.8
12	3000	7	Air	16	S4.0	0.5 · 0.7
AL N2
Thickness (mm)	Cutting Power （W）	Focus （mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	3000	1.0	N2	12	S2.0	30 · 40
2	3000	1.5	N2	12	S2.0	15 · 20
3	3000	2.0	N2	12	S2.0	8 · 10
4	3000	2.5	N2	13	S2.5	5 · 6.5
5	3000	3.0	N2	14	S2.5	2.8 · 3.5
6	3000	3.5	N2	14	S3.0	2 · 2.5
8	3000	4.0	N2	15	S3.0	0.8 · 1.3
10	3000	4.5	N2	15	S3.0	0.5 · 0.65
12	3000	5.0	N2	16	S3.0	0.3 · 0.45
Copper
Thickness (mm)	Cutting Power （W）	Focus （mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	3000	0	N2	8	S1.5	15 · 18
2	3000	1	O2	10	S1.5	7 · 9
3	3000	2.5	O2	10	S1.5	3 · 3.5
4	3000	3	O2	10	S2.0	1.5 · 2
5	3000	4	O2	10	S2.5	0.8 · 1
Brass N2
Thickness (mm)	Cutting Power （W）	Focus （mm）	Cutting Gas	Gas pressure（bar）	Nozzle type (S-Single，D-Double)	Cutting Speed (M/Min)
1	3000	0.5	N2	12	S2.0	22 · 30
2	3000	1.5	N2	13	S2.0	10 · 14
3	3000	2.5	N2	14	S2.0	5 · 7
4	3000	3	N2	14	S2.5	3 · 4
5	3000	3.5	N2	15	S2.5	2 · 2.5
6	3000	4	N2	16	S3.0	1.3 · 1.5
8	3000	4.5	N2	16	S3.0	0.5 · 0.8
Note: 1) All the lens inside the laser head need clean. 2) Cutting gas purity meets the requirements O2:99.95%,N2:99.99%. 3) Plate meets laser cutting requirements (smooth surface, no rust, no paint, etc.) 4) AL is high reflection lens, Mass produce thickness is 1-6MM.
