Name: Hengwang 1100m Fully Hydraulic Core Drilling Rig SPT 2026 CE Core Samples Geological Exploration Gold Mine Drilling Rig Diesel
SKU: B2B-37920
Price: 3270.0 USD
Availability: PreOrder

Product description

Model	HW-YDX-400XL	HW-YDX-600XL	HW-YDX-600GL	HW-YDX-800XL	HW-YDX-800GL	HW-YDX-1000GL
Drilling capacity
Diameter	HTW-NTW-BTW	HTW-NTW-BTW	HTW-NTW-BTW	HTW-NTW-BTW	HTW-NTW-BTW	HTW-NTW-BTW
Depth(m)	180-400-500(M)	200-600-650(M)	200-600-650(M)	400-800-1000(M)	400-800-1000(M)	500-1000-1100(M)
Hydraulic system
Rated pressure(Mpa)	21(MPA)	21(MPA)	21(MPA)	25(MPA)	25(MPA)	28(MPA)
Rated flow(L/min)	168(L/min)	192(L/min)	192(L/min)	260(1./min)	260(1./min)	300(L/min)
Cooling type	Air cooling + Water cooling	Air cooling + Water cooling	Air cooling + Water cooling	Air cooling + Water cooling	Air cooling + Water cooling	Air cooling + Water cooling
Engine
Engine Brand	Yuchai	Yuchai	Yuchai	Yuchai	Yuchai	Cummins
Type	Turbocharge	Turbocharge	Turbocharge	Turbocharge	Turbocharge	Turbocharge
Rated rotary speed(rpm)	2400(RPM)	2400(RPM)	2400(RPM)	2400(RPM)	2400(RPM)	2400(RPM)
Rated power(KW)	78/70	92	92	92 (6 cylinders)	92 (6 cylinders)	154
Power head
Maximum torque(Nm)	300-500(N.M)	450-1000(N.M)	450-1000(N.M)	950-1300(N.M)	950-1300(N.M)	1000-3500(N.M)
Maximum rotary speed(rpm)	1300(RPM)	1300(RPM)	1300(RPM)	1300(RPM)	1300(RPM)	1300(RPM)
Feeding stroke(mm)	1900(MM)	1900 (MM)	1900 (MM)	2400 (MM)	2400 (MM)	3500(MM)
Drilling tower
Type	Ground contact integrated drilling tower	Ground contact integrated drilling tower	Ground contact integrated drilling tower	Ground contact integrated drilling tower	Ground contact integrated drilling tower	Ground contact integrated drilling tower
Drilling angle(°)	45-90(°)	45-90(°)	45-90(°)	45-90(°)	45-90(°)	45-90(°)
Lifting force(T)	12(T)	16(T)	16(T)	24(T)	24(T)	30(T)
Feeding force(T)	6(T)	8(T)	8(T)	12(T)	12(T)	15(T)
Winch
Lifting force(KG)	500(KG)	600(KG)	600(KG)	600(KG)	600(KG)	1000(KG)
Rotary speed(rpm)	100-240(RPM)	100-300(RPM)	100-300(RPM)	100-300(RPM)	100-300(RPM)	100-300(RPM)
Wire rope diameter(mm)	6(MM)	6(MM)	6(MM)	6(MM)	6(MM)	6(MM)
Rope capacity(m)	500(M)	600(M	600(M	800(M)	800(M)	1000(M)
Traveling system
Type	Manual + remote control	Manual + remote control	Manual + remote control	Manual + remote control	Manual + remote control	Manual + remote control
Traveling speed(km/h)	2.5(KM/H)	3.5(KM/H)	3.5(KM/H)	3.5(KM/H)	3.5(KM/H)	3.5(KM/H)
Climbing angle(°)	45(°)	45(°)	45(°)	45(°)	45(°)	45(°)
Hydraulic mud pump
Mud Pump	BW-90	BW-90	BW-90	BW-90	BW-90	BW-160
Flow(L/min)	30-90(L/min)	30-90(L/min)	30-90(L/min)	90-180(L/min)	90-180(L/min)	90-180(L/min)
Pressure(Mpa)	4-7(MPA)	4-7(MPA)	4-7(MPA)	4-7(MPA)	4-7(MPA)	4-7(MPA)
Transport dimension(mm)	400019001800(MM)	400020001800(MM)	400020001800(MM)	550021002000(MM)	550021002000(MM)	600022002400(MM)
Weight(T)	4.3(T)	4.5/5.5(T)	4.5/5.5(T)	6.5(T)	6.5(T)	7.5(T)

Certifications & compliance

Complies with EU standards

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

10 days
Step 3

Packaging and dispatch

Packaging details are available on request.

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 30 fields

Usage

Ore

Type

water well drilling rig

Drilling Depth

Max.1100m

Drilling Diameter

60 mm(2.36in), 300 mm(11.81in), 50 mm(1.97in), 75mm(2.95in), 100 mm(3.94in), 200 mm(7.87in)

Power Type

Diesel

Voltage

220V/380V

Core components

Motor, Engine, Pump

Warranty

1 Year

Machinery test report

Provided

Video outgoing-inspection

Provided

Key selling points

High Safety Level

Place of origin

China, Shandong

Weight

7500 KG(16534.67lb)

Dimension (L*W*H)

6000*2200*2400mm(236.22*86.61*94.49in)

Diameter

HTW-NTW-BTW

Depth

500m-1000m-1100m

Rated pressure

28Mpa

Rated flow

300L/min

Cooling type

Air cooling + Water cooling

Engine type

Turbocharge

Rated power

154KW

Traveling speed

3.5km/h

Power head Maximum torque

1000-3500Nm

Power head Feeding stroke

3500mm

Selling Units

Single item

Single package size

600X220X240 cm

Single gross weight

7500.0 kg

Model number

HW-YDX-400XL, HW-YDX-600XL, HW-YDX-600GL, HW-YDX-800XL, HW-YDX-800GL, HW-YDX-1000GL

Power (W) (Product option)

92KW(123.37hp), 78KW(104.60hp), 154KW(206.52hp)

Certifications & Compliance

Lead time

10 days

Minimum order

1 Units
