| Model | 600M |
| Excitation | Ceramic packaged microfocus X-ray tube, Ag Anode 50kV |
| Detector | Optimized SDD detector (with Graphene window) |
| Resolution | 129eV FWHM |
| Filter | Multi-position automatic filter changer |
| Window | Kapton with anti-puncture window design optional |
| Battery | 7.2V Li-ion battery, 6800mAh |
| Display | Capacitive touch screen (5 inch 720P) |
| CPU | i.MX 8M Mini quad-core 1.8GHz |
| Signal Processor | 4096-pixel multi-channel detector / 80 MHz ADC digital signal processor |
| Data Storage | Over 100,000 data storage |
| Data Transfer | WiFi, USB |
| Structure Design | Unique structure design, effectively increases heat dissipation of the X-ray tube |
| Radiation Safety | Safety guard induction device: when no sample is in the test area, the source will shut off, providing maximum safety protection. Password-protected user security |
| Camera (optional) | Integrated CCD camera with autofocus lens for positioning and recording measurement points |
| Elements | o, Nb, Zr, Bi, Pb, Se, W, Zn, Cu, Ni, Co, Fe, Mn, Cr, V, Ti, As, Rb, Sr, K, Ca, Ba, Cd, Hg, Br, Sb, Sn, Cs, Te, Ag, Y, U, Th, Sc, Pd, Re, Ta, Hf, Mg, Al, Si, P, S |
| Environment | Temperature: -10°C~50°C, Humidity: 0%~80% |
| Weight | Approx. 1.5kg (3.3 lbs) including battery |
| Dimensions | L x W x H: 220mm x 91mm x 276mm |
| Optional | With the innovatively designed |
| Special Accessories | In addition to conventional accessories, optional: welding mask, hot surface adapter. It can detect high-temperature surfaces and vibrating surfaces without contact. |
