YH-H2O-50 Series
Max.Pressure
420 MPa/60000PSI
Max Continuous Pressure
55,000 PSI
Max. Water Flow
3.7L/min
Max. Orifice Diameter
0.35
Hydraulic oil tank Capacity
170L
Attenuator Volume
.26 gal (1L)
Water Inlet Pressure
≥0.2MPa
Power of Main Motor
37kw
Power Supply Voltage
380v/50HZ
Note: Motor horsepower can be customized. Support frequency conversion / Transformer.
Boosting Ration
20:1
0.33
Hydraulic Reservoir Capacity
30 gal (114L)
Rated Power
Max. Pressure
6000 PSI(4137bar)
Max. Flow
2.841/min
Operating Voltage and Power
210-240/360-420V 50HZ
Ambient Operating Temperature
5℃-40℃（41℉-104℉）
Long
52.15in(132cm)
Width
53.75in(136cm)
High
42.5in(106cm)
Weight
700KG
Stable performance and easy operation In order to make users use safe, stable and easy-to-operate equipment, our company has sent designers to investigate and communicate with customers on the spot for many times, and adopted the valuable opinions of customers. The user interface uses simple operating pressure gauges and regulators, as well as electric lights, emergency stop buttons, timers and induction lights, so that customers can use them safely and satisfactorily. At the same time, we also use automatic shutdown sensor to monitor the low level of hydraulic oil, high temperature of hydraulic oil, low inlet pressure and supercharger speed. Slow start function can gradually increase the user-defined preset value of hydraulic pressure, thereby prolonging the service life of the pump. Constant temperature control of imported cooling water can improve pump performance and optimize the use of water intake. In addition to excellent performance and high stability, all products are designed with safety elements. The equipment can operate safely, stably and continuously in harsh industrial cutting applications.
90000 PSI
Max. Output Flow Rate
1.4 gal
Max. Single Orifice
0.33 mm
Recommend meach Orifice
0.33inch*1 or 0.26inch*2
Motor Horse Power
100
3Phase Voltage
190 to 415(50HZ) 200 to 460(60HZ)
Full Load Watt
75kw
Recommend Inlet Water Pressure/Flowrate
Over 15/4
Ambient Temperature
2℃-49℃
Relative Humidity
up to 90% @38℃
Overall Dimensions
1458mm*14046mm*1120mm
3400KG
has developed 87000PSI ultra-high pressure pump according to the needs of the industry. The maximum pressure can reach 600MPa. The pressure is stable, which provides a strong backup for the continuous working environment. 1. Cut table new materials, improve cutting quality and increase maximum cutting thickness (up to 400 or 500 mm) 2. Increasing Cutting Speed 3. Reduce abrasive consumption (30% to 40%) 4. Cutting harder materials, such as ceramics 5. Possible Reduction of Cutting Width and CutTaper 6. Cut table New Materials to Improve Cutting Quality
Products
Waterjet / One-Stop Service Provider
As one of the most professional portable machine manufacturersand suppliers, we're featured by customized products made
. Please rest assured to buy high quality portable machine
in stock here from our factory. For price consultation
For more information, please consult us.
Note
Motor horsepower can be customized.
Support frequency conversion / Transformer.
YH-H2O pump uses easy-operate intensifier with a perfect design, durable, reliable water jet pump.
Feature
SIEMENS main motor
Customized Hydraulic pump
Booster Pump w/10 Micron Filter and oil Pressure Gauge - Automatic bleed down valve as a safety element which depressurizes the HP tubing when pump is stopped - Automatically quit on condition of super pressure or lower pressure for protection Ÿ - Adjustable pressure, Manual stepless adjustment
Stable performance and easy operation
In order to make users use safe, stable and easy-to-operate equipment, our company has sent
designers to investigate and communicate with customers on the spot for many times, and adopted the valuable opinions of
customers. The user interface uses simple operating pressure gauges and regulators, as well as electric lights, emergency stop
buttons, timers and induction lights, so that customers can use them safely and satisfactorily. At the same time, we also use
automatic shutdown sensor to monitor the low level of hydraulic oil, high temperature of hydraulic oil, low inlet pressure and
supercharger speed. Slow start function can gradually increase the user-defined preset value of hydraulic pressure, thereby
prolonging the service life of the pump. Constant temperature control of imported cooling water can improve pump performance and
optimize the use of water intake. In addition to excellent performance and high stability, all products are designed with
safety elements. The equipment can operate safely, stably and continuously in harsh industrial cutting applications.
has developed 87000PSI ultra-high pressure pump according to the needs of the industry. The maximum pressure can reach
600MPa. The pressure is stable, which provides a strong backup for the continuous working environment.
1. Cut table new materials, improve cutting quality and increase maximum cutting thickness (up to 400 or 500 mm)
2. Increasing Cutting Speed
3. Reduce abrasive consumption (30% to 40%)
4. Cutting harder materials, such as ceramics
5. Possible Reduction of Cutting Width and CutTaper
6. Cut table New Materials to Improve Cutting Quality
