| Specification | EC85-510 | EC85-320 | EC85-144 | EC85-120 | EC85-108 | EC85-60 | EC85-24 |
| Rated Voltage | 510V | 320V | 144V | 120V | 96～144V | 48～72V | 24V |
| Rated Rotational Speed | 6000rpm | 6000rpm | 4000rpm | 3200rpm | 4000rpm | 3500rpm | 3800rpm |
| Rated Current | 6A | 7A | 10A | 13.5A | 13.5A | 26A | 32A |
| Stator Outer Diameter | 85mm | 85mm | 85mm | 85mm | 85mm | 85mm | 85mm |
| Rated Torque | 3.5Nm | 3.4Nm | 3.1Nm | 3.6Nm | 3.1Nm | 3.4Nm | 2Nm |
| Efficiency | 91% | 91% | 90% | 90% | 90% | 90% | 88% |
| Stator Stack Height | 60mm | 60mm | 50mm | 60mm | 50mm | 50mm | 50mm |
| Rated Power | 2.2kw | 2.1kw | 1.3kw | 1.2kw | 1.3kw | 1.24kw | 0.8kw |
| Insulation Class | E | E | E | E | E | E | E |
| Specification | EC100-600 | EC100-540 | EC100-320 | EC100-300 | EC100-288 | EC100-144 |
| Rated Voltage | 600V | 540V | 320V | 300V | 288V | 144V |
| Rated Rotational Speed | 6000rpm | 4000rpm | 6000rpm | 7000rpm | 6000rpm | 6000rpm |
| Rated Current | 9A | 7A | 14A | 13.5A | 14.5A | 31A |
| Stator Outer Diameter | 100mm | 100mm | 100mm | 100mm | 100mm | 100mm |
| Rated Torque | 7.5Nm | 4.5Nm | 7.5Nm | 5.5Nm | 5.9Nm | 7.5Nm |
| Efficiency | 91% | 90% | 90% | 90% | 90% | 90% |
| Stator Stack Height | 50mm | 38mm | 50mm | 38mm | 50mm | 50mm |
| Rated Power | 4.7kw | 1.9kw | 4.7kw | 4.0kw | 3.7kw | 4.7kw |
| Insulation Class | E | E | E | E | E | E |
| Model | EC112-110 | EC112-450 |
| Rated Voltage | 110V | 450V |
| Rated Speed | 5000rpm | 4000rpm |
| Rated Current | 16.5A | 9.3A |
| Stator Outer Diameter | 112mm | 112mm |
| Rated Torque | 3.5Nm | 4.3Nm |
| Efficiency | 91% | 91% |
| Stator Stack Height | 25mm | 38mm |
| Rated Power | 1.8kw | 1.8Kw |
| Insulation Class | E | E |
| Specification | EC125-580 | EC125-510 | EC125-380 | EC125-110 |
| Rated Voltage | 580V | 510V | 380V | 110V |
| Rated Rotational Speed | 4500rpm | 3600rpm | 5000rpm | 3600rpm |
| Rated Current | 27A | 11A | 22A | 26A |
| Stator Outer Diameter | 125mm | 125mm | 125mm | 125mm |
| Rated Torque | 21Nm | 8.5Nm | 17Nm | 8Nm |
| Efficiency | 92% | 92% | 92% | 91% |
| Stator Stack Height | 100mm | 75mm | 85mm | 75mm |
| Rated Power | 4.7kw | 1.9kw | 4.7kw | 4.0kw |
| Insulation Class | E | E | E | E |
Minimum order: 1 Units
Payment terms, specifications, and order details are confirmed before preparation begins.
Lead time will be confirmed with your quotation.
Packaging details are available on request.
Final packing, freight, and delivery dates are confirmed before dispatch.
