New Automatic Wet Weak Magnetic Field Separator for Gold Mining High Recovery Rate 50-300 Tph Fine Mineral Ore Beneficiation

Product Importer Gallery 01 · 8be6e68be2

Product Importer Gallery 02 · 85158af44a

Product Importer Gallery 03 · b249409e46

Product Importer Gallery 04 · 3f253b46b8

Product Importer Gallery 05 · 2b3b7ef1a4

New Automatic Wet Weak Magnetic Field Separator for Gold Mining High Recovery Rate 50-300 Tph Fine Mineral Ore Beneficiation

Name: New Automatic Wet Weak Magnetic Field Separator for Gold Mining High Recovery Rate 50-300 Tph Fine Mineral Ore Beneficiation
SKU: 3MNM-WYWT-2GSC
Price: 4890.0 USD
Availability: PreOrder

Available for enquiry 0.0 · 0 reviews

USD

$ 4,890.00 4890.0 USD $ 4,890.00

Minimum order quantity: 1 Units

Key attributes

View all

Type

Magnetic Separator

Voltage

380 V, 220 V

Core components

Bearing, PLC, Motor, Pressure Vessel, Gear, Pump, Other

Machinery test report

Provided

Warranty

More Than 5 Years

Video outgoing-inspection

Provided

Order this product

Chat available

Order quantity

Closed-loop order inspection and delivery process

Your order, safely delivered

The same protected process applies to small and large orders.

Step 1

Order and payment

Pay our local business partner by local bank transfer, or use an agreed payment arrangement.
Step 2

Pre-shipment proof

We inspect the actual items and share product photos and video before dispatch.
Step 3

Local-office dispatch

The sealed shipment travels to our local office in your country.
Step 4

Inspect and deliver

Our local representative checks it, shares images and video, then confirms your delivery date.

Shipping

Shipping fees and delivery dates are confirmed with your quotation.

Secure payments

Payments are processed securely by the payment providers enabled on this website.

Buyer protection

Order protection is subject to your published commercial and refund policies.

Share this listing

Product description

Wet weak magnetic field CXJ

Production capacity: 10-150t/h

Wet weak magnetic field CXJ Principle

When the raw materials flow into the tank body of the wet drum magnetic separator, firstly, the flowing direction of the raw materials is the same as the rotary direction of the magnetic drum, the iron magnetite materials are attracted to the surface of drum. This is the first separation. In the second step, the flushing water below flush the raw materials back for the second separation. This time the flowing direction of the raw materials is opposite to the rotary direction of the magnetic drum. Then along with the rotation of drum, the iron magnetite materials on the surface of drum will finally leave the magnetic field and fall to the ore concentrate box under gravity. Also, the flushing water above helps to flush the iron magnetite into the ore concentrate box. The weak magnetic and non-magnetic materials can not be attracted and will flow to the discharge pipe for tailings.

Advantages

Optimized design

Scientific magnetic circuit, made of strong magnetic coercive force

High-remanence permanent magnet

Safe and reliable.

Product Parameters

Weak magnetic field Permanent magnetic drum wet separator
Model	cylinder size(diameter ×length)mm	cylinder surface magnetic field strength(T)	Production capacity	MotorPower(kw)	cylinder speed(r/min)	gross weight(kg)
center pole	Scavenging district	Midfielder strong magnetic field	t/h	m3/h
CTB-44	400×400	130	180	250-400	1-2	4-5	1.1	45	350
CTB-46	400×600	130	180	250-400	2-3	5-10	1.1	45	600
CTB-63	400×300	140	180	250-400	3-5	8-15	1.1	40	600
CTB-66	400×600	140	180	250-400	5-10	10-30	1.1	40	750
CTS-69 CTB-69	600×900	180	180	250-400	8-15	20-50	1.1	40	830
910
CTS-612 CTB-612	600×1200	140	180	250-400	10-20	25-60	2.2	40	960
1050
CTS-618 CTB-618	600×1800	140	180	250-400	15-30	40-80	2.2	40	1340
1340
CTS-712 CTB-712	750×1200	160	200	300-500	15-30	40-80	3	35	1500
CTS-718 CTB-718	750×1800	160	200	300-500	20-45	60-100	3	35	2100
CTS-918 CTB-918	900×1800	170	200	300-600	25-55	70-120	4	28	2900
CTS-924 CTB-924	900×2400	170	200	300-600	35-70	80-130	4	28	3600
CTS-1018 CTB-1018	1050×1800	180	220	300-700	40-75	110-160	5.5	22	4000
CTS-1021 CTB-1021 CTN-1201	1050×2100	180	220	300-700	50-100	140-200	5.5	22	4500
CTS-1024 CTB-1024 CTN-1204	1050×2400	180	220	300-700	60-120	170-260	5.5	22	5000
CTS-1030 CTN-1230 CTB-1030	1050×3000	180	220	300-700	70-150	200-320	7.5	22	6300
CTS-1218 CTB-1218	1200×1800	180	220	300-700	60-110	150-230	5.5	19	4900
CTS-1224 CTB-1224	1200×2400	180	220	300-700	70-130	80-300	7.5	19	5900
CTS-1230 CTB-1230	1200×3000	180	220	300-700	80-160	250-400	7.5	19	7200
CTS-1530 CTB-1530	1500×3000	180	220	300-700	100-180	290-480	11	14	8900
CTS-1540 CTB-1540	1500×4000	180	220	300-700	115-220	300-540	11	14	9900

Marketing Center Address: Room 1106,Rongcheng Buliding,Jianshe Road,Zhengzhou

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

2 days
Step 3

Packaging and dispatch

Packaging details are available on request.

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 21 fields

Type

Magnetic Separator

Voltage

380 V, 220 V

Core components

Bearing, PLC, Motor, Pressure Vessel, Gear, Pump, Other

Machinery test report

Provided

Warranty

More Than 5 Years

Video outgoing-inspection

Provided

Key selling points

Automatic, High Rigidity

Production Capacity

115-220

Place of origin

China, Henan

Weight

9900 KG(21825.76lb)

Dimension (L*W*H)

1500*4000

Application

Gold Mining

Usage

Mining Separatoion

Capacity

50-300 Tph

Feature

High Recovery Rate Easy

After-sales Service Provided

Service Machinery Overseas

Selling Units

Single item

Single volume

0 cm3

Single gross weight

0.0 kg

Model number

CTS,CTB,CTN

Power (W) (Product option)

Lead time

2 days

Minimum order

1 Units
