HDPE Pipe Micro Duct One 7 Ways 24 Way 16/12 14/10 12/8 10/6 mm Direct Buried Micro Duct Tube Bundle Micro Duct

Product Importer Gallery 01 · 345996976b

Product Importer Gallery 02 · 5ba2381da9

Product Importer Gallery 03 · a3da000477

Product Importer Gallery 04 · 928365127f

Product Importer Gallery 05 · b96c60cb27

Product video

Certifications CPR(2) · RoHS · EN 15494

HDPE Pipe Micro Duct One 7 Ways 24 Way 16/12 14/10 12/8 10/6 mm Direct Buried Micro Duct Tube Bundle Micro Duct

Name: HDPE Pipe Micro Duct One 7 Ways 24 Way 16/12 14/10 12/8 10/6 mm Direct Buried Micro Duct Tube Bundle Micro Duct
SKU: 33P3-M5DQ-JZ2Z
Price: 20.0 USD
Availability: PreOrder

Available for enquiry 0.0 · 0 reviews

USD

$ 20.00 20.0 USD $ 20.00

Minimum order quantity: 100 Units

Key attributes

View all

Material

HDPE, 100% virgin HDPE

Processing Service

Moulding, Cutting

Place of origin

China, Henan

Thickness (Specification)

customization

Model number (Specification)

Micro Duct Tube Bundle

Specification (Specification)

7 Ways 16/12 14/10 12/8 10/6 Mm, 20mm-1400mm

Order this product

Chat available

Order quantity

Closed-loop order inspection and delivery process

Your order, safely delivered

The same protected process applies to small and large orders.

Step 1

Order and payment

Pay our local business partner by local bank transfer, or use an agreed payment arrangement.
Step 2

Pre-shipment proof

We inspect the actual items and share product photos and video before dispatch.
Step 3

Local-office dispatch

The sealed shipment travels to our local office in your country.
Step 4

Inspect and deliver

Our local representative checks it, shares images and video, then confirms your delivery date.

Shipping

Ocean freight via Maersk · Approx. shipping fee: $ 0.84 for 1 unit · Transit time: Est. 17-24 days

Secure payments

Payments are processed securely by the payment providers enabled on this website.

Buyer protection

Order protection is subject to your published commercial and refund policies.

Share this listing

Product description

INNER TUBES	Materials	HDPE (High-density Polyethylene)
Diameter	12/10mm
Color options	Red, Green, Orange, White, Blue, Brown, Gray
Inner surface	Ribbed with silicon
Layer	2
Numbers	7
OUTER SHEATH	Materials	HDPE (High-density Polyethylene)
Thickness	3.4mm (Nominal)
Diameter (min./max.)	42.8mm(卤1.7mm)
Color	Orange/Black

OD	ID	Wall thickness	Weight	Drum size
7	3.5	1.75	0.266	2000*1100
7	4	1.5	0.247	2000*1100
10	6	2	0.430	2350*1100
12	8	2	0.531	2200*1100
14	10	2	0.631	2200*1100
16	12	2	0.736	2200*1100
20	16	2	0.929	2350*1100

Certifications & compliance

RoHS

RoHS compliant

CPR(2)

Compliant with EU regulations

EN 15494

Safety Certified

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 100 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

15 days
Step 3

Packaging and dispatch

Ocean freight via Maersk · Approx. shipping fee: $ 0.84 for 1 unit · Transit time: Est. 17-24 days

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 20 fields

Material

HDPE, 100% virgin HDPE

Processing Service

Moulding, Cutting

Place of origin

China, Henan

Thickness (Specification)

customization

Model number (Specification)

Micro Duct Tube Bundle

Specification (Specification)

7 Ways 16/12 14/10 12/8 10/6 Mm, 20mm-1400mm

Length

Customization

Standard

standard

Name

Microduct Tube Bundle

Color

White, Green, red, blue Fully colored

Connection

Microduct connector

Operating temperature

30 degree+60 degree

Density

0.940~0.958 g/cm3

Feature

Corrosion Resistant

Pressurization

No damage and leakage

Heat Reversion

≤ 3%

Selling Units

Single item

Single package size

60X80X80 cm

Single gross weight

1.0 kg

Certifications & Compliance

CPR(2), RoHS, EN 15494

Lead time

15 days

Minimum order

100 Units
