is a leading large professional industrial hose pump supplier from small flow to 502000L/H.
It is mainly used for large flow conveying and metering in industrial occasions.
Peristaltic Hose Pump and Foam Concrete Pump Introduction
The industrial hose pump is a new, multifunction and multipurpose industrial pump developed on the basis of foreign advanced technologies. It breaks away the restrictions of traditional pump impeller and shaft seal and uses the totally different mechanism compared with traditional pump. So it is very suitable to transport materials with high viscosity, high corrosivity and high content of solid particles.
Group by application: foam concrete pump, ceramic glaze pump, cement pump, mortar pump, grout pump, slurry pump, sewage pump, crude oil pump, chemical pump, deep well pump, mud pump, sludge pump, drain pump, medical pump, mining pump, food grade pump etc.
Peristaltic Hose Pump and Foam Concrete Pump Features
Unique structure with no sealing element, no leakage, no pollution
Advanced rolling technology adopted, no need of lubrication for roller
High suction ability, self-cleaning ability, sucking materials in two directions
Simple hose installation, simple operation, easy to assemble and maintain, lower maintenance cost
Linear regulation of flow rate, measuring ability
No block when pumping fluid with high viscosity and foreign substance contained
Long service life
High delivery lift and output pressure.
Peristaltic Hose Pump Working Principle
There is a specially made rubber hose with smooth inner surface and high strength installed in the pump body. When a pair of roller rotate and squeeze the hose, the rotation and squeezing force will force the transported material flow in single direction and with no back flow. After the material in hose is transported, the squeezed hose will return to its normal shape by its elasticity and pressing force of side rollers. During this procedure, the vacuum generated will suck the material into hose cavity, and then, the sucked material will be squeezed by coming rollers and discharged from the output again. With the continuous rotation of roller, the material is sucked and discharged continuously.
Peristaltic Hose Pump and Foam Concrete Pump Application Areas
Our industrial hose pumps are used to transport the materials in following industries
Phosphate fertilizer and compound fertilizer industry: Thick pasty stock and sedimentary sludge in spraying and granulating; Quantitative transportation in labs.
Mining and mineral separation: Filling materials in gold mining, pasty mined slurry, sewer drainage, sorbent, grout and mortar, etc
Chemical: Pulp of acid, alkali and phosphate; Inorganic salt such as titanium dioxide(TiO2); Crystallized liquid, suspending fluid, emulsion, resin, ooze and any acid or alkali pasty materials.
Wastewater treatment: Silt slurry and lime mortar.
Oil industry: Slurry in well drilling, crude oil.
Ceramics: Ceramic slurry, glaze slurry and frit.
Papermaking: Paper pulp, sulfur slurry.
Cosmetic: Toothpaste, emulsion, shampoo, hair conditioner, face cream and face oil.
Construction: Sewerage, drainage of deep tunnel, cement slurry, concrete slurry and ceiling painting.
Electric plating and electrolysis: Electroplating solution, electrolyte, anode slime and deposit.
Food industry: Oil and beverage
Pharmacy: All kinds of pharmaceutical material and liquid
Besides above materials, our industrial hose pump can also transport other liquids with high sealing requirements, high viscosity and large quantity of solid particles contained, such as radioactive liquid waste, electrolytic waste, liquid contained metal, oil paint, coating materials, auxiliary agent in printing and dyeing, bond, glue, latexes and refractory fibre slurry, etc.
IHP Series
IHPG Series
Peristaltic Hose Pump and Foam Concrete Pump Models
Factory
Certifications
FAQ 1. Are you manufacturer? Ans: Yes, we are factory with more than 20 years manufacturing experience.We have our own 15000 m2 factory and one share-controlled company for manufacturing rubber hose. We welcome you to visit our factory and arrange person to inspect product before delivery.
2. What is the terms of payment? Ans: T/T 30% deposit, T/T 70% before delivery. We’ll share the photos of the products and packages along with invoice and packing list.For big order,we can also accept L/C.
3. What is the terms of delivery? Ans: EXW, FOB, CFR,CIF
4. How about the delivery time? Ans: We have mold for all models of our hose pump.Generally it takes 7-10 working days after receiving the advance payment. The specific delivery time depends on the items and the quantity of the order and the requirements of customers.
5. What is the warranty of the machine? Ans: Our main machine enjoys 1 year warranty, all accessories broken can apply a new one during this time, and we offer video supporting installation,operation and maintenance.
6. What is your packing like? Ans: We use standard exporting wooden case.
7. Will you test the goods before delivery? Ans: Yes, we will test 100% before packing.
Group by application
foam concrete pump, ceramic glaze pump, cement pump, mortar pump, grout pump, slurry pump, sewage pump, crude oil pump, chemical pump, deep well pump, mud pump, sludge pump, drain pump, medical pump, mining pump, food grade pump etc.
Peristaltic Hose Pump and Foam Concrete Pump
Application Areas
Phosphate fertilizer and compound fertilizer industry
Thick pasty stock and sedimentary sludge in spraying and granulating; Quantitative transportation in labs.
Mining and mineral separation
Filling materials in gold mining, pasty mined slurry, sewer drainage, sorbent, grout and mortar, etc
Chemical
Pulp of acid, alkali and phosphate; Inorganic salt such as titanium dioxide(TiO2); Crystallized liquid, suspending fluid, emulsion, resin, ooze and any acid or alkali pasty materials.
Wastewater treatment
Silt slurry and lime mortar.
Oil industry
Slurry in well drilling, crude oil.
Ceramics
Ceramic slurry, glaze slurry and frit.
Papermaking
Paper pulp, sulfur slurry.
Cosmetic
Toothpaste, emulsion, shampoo, hair conditioner, face cream and face oil.
Construction
Sewerage, drainage of deep tunnel, cement slurry, concrete slurry and ceiling painting.
Electric plating and electrolysis
Electroplating solution, electrolyte, anode slime and deposit.
Food industry
Oil and beverage
Pharmacy
All kinds of pharmaceutical material and liquid
is a leading large professional industrial hose pump supplier at home and abroad. Our hose pumps are used globally and are known for low energy consumption,low and easy maintenance and exceptional build quality. Huayun is one of the national standard setter of hose pump,we produce a range of different sizes of peristaltic pump and different material of hose for choosing.We have our own factory to manufacture hose, and we have our own formulation of hose,we also export hose to many European and America countries.Our hose pump can be used in many kinds of industries.We are factory with 15000m2 rather than trading company or small working shops.If you really want to find a long-term partner,if you really want to avoid any after-sales problem in future,Huayun will be a good partner.Not just see the pictures and price some suppliers list,know one company in detail and you can find good and long-term partner.We really welcome you to visit our factory.
