Name: Rock Splitter,stone Splitting Wedge,darda Hydraulic Rock Splitter
SKU: B2B-68628
Price: 830.0 USD
Availability: PreOrder

Product description

Product Application

The Hydraulic Rock & Concrete splitter is our newly developed Product which is a powerful and extremely cost-effective alternative to other conventional demolition tools. It can develop a very huge splitting force (Maximum 1000T) when it put into the pre-drill holes of rock or concrete,and crack it into pieces within several seconds. Now it is widely used in mineral mining (cave mining), civil engineering construction and is also an indispensable tool in construction, river dredging, salvation etc. Our main Models of hydraulic pump and cylinder are as follows. If you are interested in, please let us know which type of pump and cylinder you need. We will offer a very competitive price for you.

SPECIFICATIONS FOR ROCK SPLITTER
Rock spliter gun
Model	HW80-250	HW80-350	HW80-450	HW90-250	HW90-350	HW90-450
Piston diameter	80mm	80mm	80mm	90mm	90mm	90mm
Drilling diameter	Φ42mm	Φ45mm	Φ50mm	Φ42mm	Φ45mm	Φ50mm
Drilling depth	≧500mm	≧550mm	≧600mm	≧500mm	≧550mm	≧600mm
Cheese block length	250mm	350mm	450mm	250mm	350mm	450mm
Crack width	10～40mm
Splitting time	5～15s
Theory of separatist force	600T	600T	600T	800T	800T	800T
The actul split force	480T
Hydraulic rock splitter pump station
Engine	Electric engine	Diesel engine
Capacity of tank	15L	40L	88L	45L	65L	90L
Motor power	1.5KW	4KW	7.5KW	4HP	7HP	7.5HP
Working pressure(Mpa)	55-60
Working flow(L/min)	2—13

YN27C rock drill

91.8% Response Rate

manual splitting tools

89.8% Response Rate

Portable backpack dril machine

90.8% Response Rate

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

7 days
Step 3

Packaging and dispatch

Packaging details are available on request.

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 25 fields

Type

Rock Splitter

Motor Type

AC Motor

Core components

Pump

Machinery test report

Provided

Video outgoing-inspection

Provided

Warranty

1 Year

Weight (kg)

Place of origin

China, Shandong

Application

Stone, Concrete

Dimension (L*W*H)

450*410*700MM(17.72*16.14*27.56in)

Equiped qty of cylinder hammer

1-10

Work flow

2-13L/M, 5m

Splitting Diameter

42-45mm

Working medium

46 or 68 anti-wear

Capacity of tank

25-45L

Depth

300-800mm

Working pressure

55-60MPa

Packaging Details

Wooden case

Port of dispatch

Qingdao/Tianjin/Shanghai

Selling Units

Single item

Single package size

50X50X50 cm

Single gross weight

33.000 kg

Supply Ability

200 sets per Week rock splitter

Power (W) (Product option)

5.5kw(7.38hp)

Model number

HW90-250, HW90-350, HW90-450, HW80-350, HW80-450

Lead time

7 days

Minimum order

1 Units
