High Stable 4-Wavelength 1271/1291/1311/1331nm SMSR 35dB Point Optical Light Source 4-in-1 Singlemode Optional 1-18 Wavelength

Name: High Stable 4-Wavelength 1271/1291/1311/1331nm SMSR 35dB Point Optical Light Source 4-in-1 Singlemode Optional 1-18 Wavelength
SKU: MMWF-P883-5HQN-01
Price: 3750.0 USD
Availability: PreOrder

Available for enquiry 0.0 · 0 reviews

USD

$ 3,750.00 3750.0 USD $ 3,750.00

Minimum order quantity: 1 Units

Key attributes

View all

Type

Optical Light Source

Connector Type

FC/UPC

Use

Laboratory & Production Test

Model number (Specification)

JSXS-L5-71911131

Place of origin

China, Guangdong

Warranty time

2 Years

Order this product

Chat available

Order quantity

Closed-loop order inspection and delivery process

Your order, safely delivered

The same protected process applies to small and large orders.

Step 1

Order and payment

Pay our local business partner by local bank transfer, or use an agreed payment arrangement.
Step 2

Pre-shipment proof

We inspect the actual items and share product photos and video before dispatch.
Step 3

Local-office dispatch

The sealed shipment travels to our local office in your country.
Step 4

Inspect and deliver

Our local representative checks it, shares images and video, then confirms your delivery date.

Shipping

Ocean freight via Maersk · Approx. shipping fee: $ 0.84 for 1 unit · Transit time: Est. 17-24 days

Secure payments

Payments are processed securely by the payment providers enabled on this website.

Buyer protection

Order protection is subject to your published commercial and refund policies.

Share this listing

Product description

16+ years of professional optical communication and copper products manufacturer

➤ Applications

Paramenters	Condition	Min	Type	Max	Unit
PN	JSXS-L5-71911131
Optical Power	PO	3	2	mw
Wavelength	Single-Wavelength	1271/1291/1311/1331	nm
Center Wavelength Deviation	Wavelength	2	2	nm
Number of Channels	4
Whether with Power Adjustment	Yes
Whether With Display	Yes
Stored Program Control	R232 Serial Port Control
3dB spectral width	Δλ	0.2	0.5	nm
20dB spectral width	Δλ	0.5	1	nm
Side-mode suppression ratio	SMSR	35	dB
Output power stability (15 min）	ΔPO_15m	±0.01	±0.03	dB
Output power stability （8 hours）	ΔPO_8h	±0.03	±0.05	dB
Output Fiber Type	SMF-28e Single-Mode Fiber
Output Interface	Single-Channel FC/UPC (4-Wavelength Multiplexed Output)
TEC stability	ΔT1	±0.1	±0.2	°C
Operating voltage	V	110	240	VAC
Power loss	Pc	30	W
Operating temperature	TW	15	35	°C
Storage temperature	TS	5	40	°C
Appearance size	1-4 wavelength：320220136mm, 5-18 wavelength：Standard 3U case

High Density 1U Rack Mount Enclosure Unloaded Tool-Less Removable Top Cover for 6 Cassettes 144 Fibers Fiber Optic Equipment

Q1: Why choose as your supplier？ A1: Because we are more reliable, more efficient and more cost-effective! 16+ years professional one-stop optical communication and copper products manufacturer; All of our products 100% tested by precision machine and hold CE & RoHS certifications; Flexible MOQ & Free Sample; Rapid response and fast delivery of standard product.

Q2: Could the OEM or ODM be accepted? A2: Of course, please

Q3: Can I come and visit your factory or company? A3: Yes

Q4: How can we guarantee product quality? A4: Our Commitment —Strict quality protocols enforced at every manufacturing stage; Workshop Environment: Clean and controlled facility ensuring product performance; Expert Team: Professional QC engineers oversee strict quality control throughout production; Precision Instruments: IL/RL detection, polarity testing, 3D interferometer analysis, end-face inspection, etc.

Q5: How to transport the goods? A5: International Express/ Air Freight/ Ocean Freight

Q6: What services do we provide? A6: Accepted Delivery Terms: FOB/ EXW; Accepted Payment Currency: USD/ RMB/ EUR; Accepted Payment Type: T/T, L/C, Western Union, Cash.

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

25 days
Step 3

Packaging and dispatch

Ocean freight via Maersk · Approx. shipping fee: $ 0.84 for 1 unit · Transit time: Est. 17-24 days

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 20 fields

Type

Optical Light Source

Connector Type

FC/UPC

Use

Laboratory & Production Test

Model number (Specification)

JSXS-L5-71911131

Place of origin

China, Guangdong

Warranty time

2 Years

Optical Power

PO: 2dBm (Typical)

Wavelength

1271/1291/1311/1331nm

Stored Program Control

R232 Serial Port Control

3dB Spectral Width

0.2nm (Typical)

20dB Spectral Width

0.5nm (Typical)

Side-mode Suppression Ratio

SMSR: 35dB (Min)

Output Fiber Type

SMF-28e Single-Mode Fiber

Storage temperature

TS: -5~+40°C

Operating voltage

V: 110-240VAC

Appearance Size

1-4 wavelength:320*220*136mm, 5-18 wavelength:Standard 3U case

Selling Units

Single item

Single volume

0 cm3

Single gross weight

0.0 kg

Specification

Custom 4-Wavelength Point (4-in-1) Channel Optical Light Source

Lead time

25 days

Minimum order

1 Units
