Name: Industrial Steam Boiler Water Horizontal Steam Powered Electric Generator Automatic High Efficiency Easy Operation Long
SKU: Y9F9-2TQ5-3BDQ-01
Price: 12100.0 USD
Availability: PreOrder

Product description

$8,079.95-103,115.07 / set

Welcome to contact me for more discounts

Model	WNS0.5-1.0-YQ	WNS1.0-1.25-YQ	WNS2.0-1.25-YQ	WNS3.0-1.25-YQ	WNS4.0-1.25-YQ	WNS6.0-1.25-YQ	WNS8.0-1.25-YQ
Rated steam pressure(MPa)	1	1.25	1.25	1.25	1.25	1.25	1.25
Rated steam temperature(℃)	180	194	194	194	194	194	194
Feedwater temperature (℃)	20	20	20	20	20	20	20
Thermal efficiency(%)	≥93	≥93	≥93	≥93	≥93	≥93	≥93
Body heating area（㎡）	17	27	50	88	117	171	204
Fuel consumption	Natural gas(m³/h)	39	79	157	236	314	471	629
Liquid gas(m³/h)	31	63	126	189	251	377	503
City gas(m³/h)	83	165	330	495	660	990	1320
Light diesel(Kg/h)	32	65	129	194	259	388	518
Heavy oil(Kg/h)	33	66	132	198	264	396	528
Transport reference weight(T)	2.5	5.4	8.06	10	12.43	15.5	22
Transport reference scale (MM)	Long	3300	4100	4300	5170	5600	6300	6580
Wide	1500	1720	1900	2000	2150	2250	2620
High	1700	2050	2400	2500	2640	2700	3120
⭐All the above values are calculated based on the standard lower heating values: natural gas 8,400 Kcal/Nm³, liquefied gas 10,500 Kcal/Nm³, city gas 4,000 Kcal/Nm³, light oil 10,200 Kcal/Kg, heavy oil 10,000 Kcal/Kg.
⭐ The parameters are changed due to technical innovation, and the factory parameters are subject to the actual drawings!

Certifications & compliance

Complies with EU standards

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

15 days
Step 3

Packaging and dispatch

Ocean freight via Maersk · Approx. shipping fee: $ 0.84 for 1 unit · Transit time: Est. 17-24 days

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 27 fields

OUTPUT

Steam

Usage

Industrial

Fuel

heavy oil, Fuel and gas, Light oil, gas fuel

Pressure

Max. 2.5MP

Structure

fire and water tube

Type

Natural Circulation

Material

Q345R steel plate

Core components

boiler body

Key selling points

Automatic, Easy To Operate, Long Service Life, Low Maintenance Cost

Style

Horizontal

Warranty

2 Years

Video outgoing-inspection

Provided

Machinery test report

Provided

Weight (kg)

1000

Place of origin

China, Henan

Dimension(L*W*H)

Depends on Boiler Capacity

Color

Customized

Capacity

1-20 ton

Steam Temperature

174-225 degree

Thermal efficiency

more than 85%

Life Span

more than 30 years

Selling Units

Single item

Single volume

0 cm3

Single gross weight

0.0 kg

Steam production

Support customization

Model number

WNS0.5, WNS0.7, WNS1, WNS2, WNS3, WNS4, WNS6, WNS8, WNS10, WNS15, WNS12, WNS20

Certifications & Compliance

Lead time

15 days

Minimum order

1 Units
