Name: Industrial Direct Driven 75KW 90KW 8bar Variable Frequency Screw Air Compressor IE4 PM Motor with IoT Remote Control
SKU: B2B-34205
Price: 6100.0 USD
Availability: PreOrder

Product description

PM VSD Permanent Magnet Variable Speed Drive Screw Air Compressor Automatically Adjusts Motor Speed To Match Real Time Air Demand, Reducing Energy Consumption By 30%-35% Versus Fixed Speed Rotary Screw Compressors, Reducing Electricity Bills By 35% Annually. Full Range Coverage From 10hp To 350hp (7.5kW To 250kW) Air Flow From 0.7m³/min To 44.5m³/min, 25 cfm To 1570 cfm At 7bar To 13bar. Widely Used In Laser Cutting Machines, CNC Machine, Sandblasting, Pneumatic Tools, Painting, Auto Repair, Packaging, Wood Processing, Printing And Furniture Manufacturing.

Motor-Compressor Separated Structure Isolates Motor From Air End For Independent Servicing Without Full Disassembly, Cutting Maintenance Time By Over 60% And Making Routine Upkeep Simple Even Without Specialized Technicians On Site.

German Technology Air End, SKF Bearing, Inovance Inverter, Schneider Contactor, Plot Controller Reduces Electricity Costs By 30% To 50% Compared To Traditional Fixed Speed Industrial Compressors. IP55 Protection Rating And Durable Service Life Exceeding 15 Years, Ensuring 24/7 Continuous Operation Even In High-Temperature Environments. Vibration Dampening Base Frame, Operating At A Silent Low-Noise Level Below 68dB.

We Provide Customized Voltage Including 220V, 380V, 415V, And 440V, 600V, Single Phase, 3 Phase, 50Hz/60Hz To Match Power Grid Standards,,, Europe, South America, Middle East And Southeast Asia. CE/UL/ASME/ISO9001 Certified

Factory Direct With 1 Year Warranty And Lifetime Parts Support: As A Top Chinese Air Compressor Manufacturer With 15+ Years Of Export Expertise, We Offer Competitive Factory-Direct Pricing And A Comprehensive 12 Month Warranty On Core Components. We Provide 2 Hours Rapid Response Technical Support And Maintain A Full Inventory Of Spare Parts For Immediate Worldwide Shipping. Every Unit Undergoes A Rigorous 72 Hours High-Pressure Load Test Before Shipment. OEM/ODM Available For Voltage, Pressure, Color, And Logo.

PM VSD 75KW 100HP Screw Air Compressor Specification	Permanent Magnet Variable Frequency Screw Air Compressor Specification
Key Specifications	Values (US Standard)	Metric Reference
Merchant Identity	Professional Custom Manufacturer / OEM / ODM	Professional Custom Manufacturer / OEM / ODM
Model	BPM-100A-S	BPM-100A-S
Motor Power	100 HP	75 kW
Free Air Delivery / Discharge Pressure	477 CFM @ 102 PSI 445 CFM @ 116 PSI 396 CFM @ 145 PSI 353 CFM @ 189 PSI	13.5 m³/min @ 7 bar 12.6 m³/min @ 8 bar 11.2 m³/min @ 10 bar 10.0 m³/min @ 13 bar
Power Supply	220V/ 230V/ 460V / 480V/ 60Hz	380V / 415V/ 440V / 50Hz
Air Receiver Tank	1,320 Gallon (ASME U-Stamp)	5000 Liters CE Tank
Drive Method	PM VSD — Permanent Magnet Variable Frequency Direct Drive	PM VSD — Permanent Magnet Variable Frequency Direct Drive
Noise Level	68 ± 2 dB(A)	68 ± 2 dB(A)
Air Outlet Diameter	2" NPT Thread (US Standard Connection)	2"
Ambient Temperature	23 °F – 113 °F	5 °C to +45 °C
Net Weight	1,984 lbs	900 kg
Dimensions (L x W x H)	70.8" × 45.6" × 58.6"	1,800 * 1,160 * 1,490 mm
Standard Compliance	ASME, UL-Listed Electricals, CE	ISO 9001, CE, ASME
Protection / Insulation	IP55 Protection; Class F Insulation	IP55 Protection; Class F Insulation
Delivery Time	In Stock: 3-7 days	In Stock: 3-7 days
Shipping	Special DDP Sea Freight Shipping available. Request a quote with your Zip Code	EXW, FOB, CIF Or DDP Shipping Cost
Package	Standard Export Wooden Crate	Standard Export Wooden Crate
Spare Parts	3-Day Express Spare Parts to Anywhere via DHL/FedEx	3-Day Express Spare Parts to Anywhere via DHL/FedEx
The ROI Analysis	The Math: An average US factory running two shifts can save 4,500−4,500−7,000 per year in energy costs. The machine effectively pays for itself in less than 12 months.	The Math: The factory running two shifts can save 4,500−4,500−7,000 per year in energy costs. The machine effectively pays for itself in less than 12 months.
What we can do for local distributors	1. "Your Brand
What we can do forMaintenance & Service Providers	1. "One Air End, Multiple Applications. High-Quality Compatible Spare Parts for Atlas Copco, Ingersoll Rand, Sullair & More — Just Send Us the Original Part Number." 2. "No MOQ. 1 Piece Shipped in 3-7 Days. Because We Know Your Customer's
What we can do for Equipment Supplier	1. "Every Unit Factory-Tested Under Full Load. The CFM on the Nameplate is the CFM Your System Gets — No Margin Tricks, No Empty Promises." 2. "Your Dimensions. Your Voltage. Your Color. We Engineer the Compressor to Fit Your Machine — Not the Other Way Around." 3. "Promise Date = Ship Date. We'd Rather Say 25 Days and Deliver on Day 24, Than Promise 15 and Crash Your Production Schedule." 4. "62 dB(A) Measured at 1 Meter. Ultra-Low Vibration Design Keeps Your Whole System Running Smooth — Because Your Customer Judges the Entire Machine, Not Just the Compressor." 5. "Lock Your Cost, Protect Your Margin. Volume-Based Annual Pricing Agreements — So Your Profit Forecast Stays Solid." 6. "We Don't Just Sell Compressors. We Engineer Air Stations That Plug Seamlessly Into Your CNC, Laser, or Nitrogen System — 3D Drawings Provided Before Production."

High Quality Screw Air Compressor Main Configuration
Parts	Brand
Air end	Gu （ technology）
Intake Valve	Red stad()
Solenoid Valve	CEME ()
Temperature sensor	Red stad()
Pressure sensor	Huba original ()
Motor	QingJiang Motor ()
Coupling	KTR
Thermostat Valve	VMC
Controller	Schneider Electric （）
Minimal Pressure Valve	Red stad()
Air filter element	MANN
Oil filter element	MANN
Oil separator element	MANN

Certifications & compliance

CE(2)

Complies with EU standards

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

7 days
Step 3

Packaging and dispatch

Ocean + Truck via Maersk · Approx. shipping fee: $ 288.32 for 1 piece · Transit time: Est. 17-24 days

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 31 fields

Type

Screw

Gas type

Air

Power source

AC Power

Lubrication style

Lubricated

Cooling Method

Air Cooled

Configuration

Stationary

Voltage

380 V, 220 V, 415V, 480V, 440V, 230v, 600V, 460V

Machinery test report

Provided

Video outgoing-inspection

Provided

Mute

Yes

Warranty

1 Year, One-year warranty for Complete machine, 18 months for Air end

Core components

Bearing, PLC, Motor, Pressure Vessel, Pump

Weight (kg)

630

Place of origin

China, Guangdong

Model number (Specification)

BPM-100A-S

Dimension(L*W*H)

1730*1170*1700mm

Air capacity

10.0- 13.5m3/min 353 CFM-477 CFM

Air end

Double Screw(Germany Technology)

Motor

IP55

Application

Industrial Equipment Air Compressor

Drive method

PM VSD Energy Saving 35% Electricity

Motor power

75KW 100HP

Pressure

8 bar, 10 bar, 13 bar, 116 psi, 145 psi,189 psi

Electricity (V/ph/Hz)

220V/230V/ 380V/ 415V/ 440V/ 460V/ 480V/ 600V

Certification

CE, ISO, ASME

Selling Units

Single item

Single package size

156X100X136 cm

Single gross weight

610.0 kg

Working pressure (Product option)

8 bar, 13 bar, 10 Bar, 7 bar, 12 bar, 16 bar, 20 bar

Power(W) (Product option)

7.5 KW, 15 kw, 37 kW, 11 kW, 315 KW, 132 KW, 90 kW, 250 kw, 55 kw, 185 kw, 160 Kw, 110 kw, 11kw/15hp, 7.5kw/10hp, 15kw/20hp, 22KW/30HP, 37KW/50HP, 45KW/60HP, 55KW/75HP, 75KW/100HP, 37KW/50H, 90KW/120HP, 110KW/150HP, 132KW/175HP, 160KW/220HP, 185KW/250HP, 220KW/300HP, 250KW/350HP

Certifications & Compliance

CE(2)

Lead time

7 days

Minimum order

1 Units
