Ultra Compact Mini Size Smallest footprint in its class: 116 × 143.5 × 76.4mm, perfectly fits narrow internal space of all self-service kiosks.
Patented Anti-Jamming Mechanism Built-in jam auto-detection, auto eject retry & printer clean command, fault rate lower than 0.5% for 24/7 unattended running.
Ultra High Printing Speed Max 250mm/s printing speed, ticket presenter eject/retract speed over 1000mm/s, handle peak customer traffic efficiently.
Full Ticket Presenter Function Support print-cut-before-present, auto eject, auto retract; patented retract-without-present mode for fiscal data storage.
Flexible Multi-Mount Design Detachable roll holder supports 6 mounting positions (left/right dual side), easy paper loading, compatible with various kiosk structures.
Large Capacity Paper Roll Standard max 180mm OD paper roll; optional external bracket supports 250mm super large roll, reduce paper replacement frequency.
Dual Standard Interfaces Standard RS232 DB9 + USB Type B; optional Ethernet port, compatible with Windows, Linux, Android, OPOS system, complete SDK & diagnostic tools.
Comprehensive Monitoring Sensors Paper present, paper near-end, paper out, printhead overheat, black mark, cover open, ticket withdrawal multi-sensor real-time status feedback.
Wide Extreme Temperature Adaptability Operating temperature: -20℃ ~ +70℃, stable printing for indoor & harsh outdoor environments like gas stations, roadside parking meters.
Super Long Service Life Electronic board MTBF: 450,000 hours; printhead lifespan up to 200km; auto cutter lifespan ≥ 1,000,000 cutting times.
Rich Barcode & Font Library Supports QR Code, PDF417, Data Matrix, Code128, EAN, UPC and all mainstream barcodes; preloaded multi-country Latin, Cyrillic, Arabic fonts.
User-Friendly Illuminated Bezel Unique green light transparent bezel, clear operation reminder for users; optional external shutter for outdoor dust & water protection
| Printing Method | Thermal with fixed head |
| Number of dots | 8 dots/mm |
| Resolution | 203 DPI / enhanced printing quality |
| Printing (mm/sec) | High speed > 250 mm/sec |
| Character set | PC437, PC850, PC860, PC863, PC865, PC858 |
| Printing Format | Normal, height and width from 1x to 8x, reverse, underlined, italic, bold |
| Printing Direction | Straight, 90°, 180°, 270° |
| Paper width | from 50 to 82.5 mm |
| Paper weight | from 55 to 110 g/m² |
| Roll Dimension | max 150mm (Up to 250mm with optional roll holder) |
| Emulation | CUSTOM/POS |
| Interfaces | RS232 + USB ETH + USB |
| Data Buffer | 16 KB text / 1MB graphics |
| Flash Memory | 5 MB (of which 1MB available to the user) |
| Drivers | Windows® (32/64 bit) – only on request WHQL and silent installation; Linux (32/64 bit); Virtual COM (Linux or Windows 32/64 bit); OPOS; Android™; iOS |
| Software Tools | PrinterSet, CustomPowerTool, Status Monitor, Custom Windows API |
| Power supply | 24 Vdc±10% |
| Medium consumption | 1A (12,5% dots turned on) |
| MTBF | 450,000 hours (electronic board) |
| Head Life | 100Km / 100 Ml pulses |
| MCBF | 1,000,000 cuts |
| Operating temperature | 20°C + 70°C |
| Dimensions | 143.5 (L) x 76.4 (H) x 116 (W) mm |
| Weight | 0.8 Kg |
Parking Payment Kiosks & Roadside Parking Meters Underground parking auto payment terminals, street parking pay stations, print parking invoices and entry tickets, large roll reduces maintenance.
ATM & Banking Self-Service Terminals Print bank transaction slips, account receipts, compact size fits ATM internal space, stable long-term operation.
Fuel & Gas Station Dispensers Wide temperature range + optional anti-dust shutter, ideal for outdoor fuel pump receipt printing, anti-oil corrosion housing.
Automatic Vending Machines Snack, beverage, retail vending equipment to print consumption receipts and warranty slips.
Lottery & Gaming Terminals Lottery self-service ticket dispensers, casino slot machines, fast high-volume barcode ticket output.
Hospital & Government Service Kiosks Registration, payment, business handling self-service terminals to print queue slips & official fiscal receipts.
Queue Management Systems Bank, telecom, hospital queuing machines for multi-language number ticket printing.
Scenic Spot & Public Transport Ticketing Terminals Subway, bus, tourist attraction self-service ticket machines for entry ticket printing.
Outdoor Unattended Industrial Equipment Road toll stations, outdoor monitoring terminals, stable performance under extreme high/low temperature.
Unmanned Retail Self-Checkout Kiosks Supermarket unmanned checkout equipment for shopping receipt printing.
Fiscal Receipt Terminals Patented retract-without-present function stores fiscal tickets for tax audit, meets global fiscal market requirements.
