Name: Counter-rotating Parallel Twin Screw Extruder for Complete Turnkey PVC PE TPU HDPE Pelletizing Sheet Production Line High
SKU: B2B-40765
Price: 71520.0 USD
Availability: PreOrder

Product description

Highlights at a glance

A Counter-rotating Parallel Double Screw Extruder is a specialized polymer processing machine characterized by two parallel screws that rotate in opposite directions within a single barrel.

Unlike co-rotating extruders which are designed for high mixing speed, counter-rotating systems are engineered for low-shear, high-pressure performance, making them the industry standard for heat-sensitive materials.

1. Working Principle

1) Positive Displacement: The opposite rotation of the screws creates a "calendering" effect, trapping material between the screw flights and the barrel to force it forward with high volumetric efficiency.

2) Low Thermal Stress: Because the screws do not generate the intense frictional heat found in co-rotating systems, the material maintains its physical properties without thermal degradation.

3) Venting & Degassing: These machines are often equipped with vacuum exhaust zones to remove moisture and volatile gases, which is critical for high-quality final products.

2. Common Applications

1) PVC Processing: The most widespread use, including rigid pipes (U-PVC), window profiles, and siding.

2) Wood Plastic Composites (WPC): Ideal for compounding wood fibers with plastics due to superior moisture removal and compression.

3) Recycling: Efficiently processes 100% recycled materials into high-quality profiles.

3. Advantages

1) Modular extruder concept with high process flexibility for various formulations and materials

2) Low maintenance effort thanks to internally tempered screws and air-cooled barrel

3) High output rates, reliable degassing, and consistent production of single- and multi-layer pipes with excellent quality

Certifications & compliance

Complies with EU standards

Frequently asked questions

(1)We have complete system of designing of extrusion equipment, so customize is available. (2)We can provide perfect extrusion management solutions and extrusion equipment. (3)We could make you in a leading position in the industry.

You should prepare raw material, workshop, water line, electric line, compress air(if you need I can help you buy air compressor). We would supply workshop layout drawing for you.

First of all, we will test the machine before shipment. we will send our engineer to your factory to assemble and adjust the machine, and teach your operators to use the machine in the right way.

Within one year after installation under normal condition operation.

Description images

Packaging and fulfilment

Step 1

Payment and order readiness

Minimum order: 1 Units

Payment terms, specifications, and order details are confirmed before preparation begins.
Step 2

Preparation

80 days
Step 3

Packaging and dispatch

Ocean freight via Maersk · Approx. shipping fee: $ 0.84 for 1 unit · Transit time: Est. 17-24 days

Final packing, freight, and delivery dates are confirmed before dispatch.

Technical specifications

Other details 32 fields

Application

Granules, Sheet, Pelletizing

Plastic processed

PE, HDPE, PVC, EVA, TPU

Extruder type

twin screw

Voltage

Other

Screw L/D Ratio

156:1

Screw Material

38CrMoALA

Key selling points

Energy Saving

Machinery test report

Provided

Video outgoing-inspection

Provided

Warranty

1 Year

Core components

Bearing, PLC, Motor, Pressure Vessel, Gear, Engine, Pump, Gearbox, Other, Screw

Screw Design

Double-screw

Screw Speed (rpm)

Place of origin

China

Weight (kg)

8000

Dimension(L*W*H)

Customized

Power (kW)

560

Name

Counter-rotating Parallel Twin Screw Extruder

Screw

Double Screws

Raw material

PVC PE Granules Powder

Processing Type

Extrusion Process

Automatic grade

High Automation

CONTROL

SIEMENS PLC+Touch Screen

After sales service

On-site Installation, Commissioning, Teaching

After Warranty Service

On-line Technical Support

Customize

Available

Selling Units

Single item

Single volume

0 cm3

Single gross weight

0.0 kg

Model number

SJP

Output (kg/h)

100, 150, 300, 450, 180, 800, 900, 1000, 750

Certifications & Compliance

Lead time

80 days

Minimum order

1 Units
